TOP 3804

Product Description

Application Scenarios

Automotive lamps, air conditioners, air purifiers, robotic vacuum cleaners, laptops, industrial control equipment, backlights, etc.

Features

This product is made of PPA material, featuring low power consumption, long service life, high brightness, low light attenuation and wide applicability, and it complies with RoHS standards.
It boasts a wide viewing angle and heat-dissipation optimized design. We adopt high-quality chips sourced from top-tier suppliers in the industry, delivering lower power draw, longer lifespan, higher luminous efficiency and uniform color output.



Color gamut values including color temperature, color rendering index (CRI) and R9 can be adjusted as per customer requirements, enabling versatile application coverage.

Product Size

Tag:

SMD LED
Inquire now Download
Product Parameters
Color Part No. Forward
Current		 Forward
Voltage		 Luminous
Flux		 CCT or Wavelength TJMax Viewing
Angle
mA V MCD K/nm ℃ Deg.
Typ Max Typ Typ Typ Max Typ
White DZ-3804WCYA-FTMJ-P001 20 30 3.0  3200 21000K 115 120
Red DZ-3804WCYA-FBMJ-P00R 20 30 2.0  1000 615-624 115 120
Green DZ-3804WCYA-FCMJ-P00G 20 30 3.0  1600 515-525 115 120
Blue DZ-3804WCYA-FCDJ-P00B 20 30 3.0  600 465-475 115 120
