EMC 3030 series

Product Description

Application Scenarios

Automotive lighting, daytime running lights, air conditioners, air purifiers, gas water heaters, robotic vacuum cleaners, backlights, general lighting and more.

Features

This product uses EMC material, with advantages of low power consumption, long service life, high brightness and low light attenuation. It complies with RoHS and AEC-Q102 standards.



It features a wide viewing angle and heat-dissipating structural design. We source premium chips from leading suppliers in the industry, which further reduces power consumption, extends service life and improves luminous efficiency.



Parameters including color temperature, color rendering index (CRI) and R9 value can be adjusted to meet customer requirements, making the product applicable to a wide range of scenarios.

Product Size

Tag:

SMD LED TOP LED
Inquire now Download
Product Parameters
Product
Color NO.		 Forward Current mA Typ. Forward Current mA Max. Forward Voltage V Typ. Luminous Flux LM Typ. CCT or Wavelength K/nm Typ. TJMax ℃ Max. Viewing Angle Deg. Typ.
DZ-3030WLYE-OAZ-X009 White 350 420 3.2 135 6000K 150 120
DZ-3030ALYE-OAZ-X018 PC Amber 350 420 3.0 85 1700K 150 120
DZ-3030RLYE-OAZ-X012 Red 350 420 2.2 75 615 150 120
DZ-3030RLYE-OAZ-X017 Red 350 420 2.2 68 620 150 120
DZ-3030RLYE-OAZ-X010 Super red 350 420 2.2 50 630 150 120
DZ-3030WLYE-NAZ-X005 White 150 200 3.0 70 6000K 150 120
DZ-3030ALYE-NAZ-X003 PC Amber 150 200 3.0 50 1700K 150 120
DZ-3030RLYE-NSZ-X001 Red 150 200 2.2 35 615 150 120
DZ-3030RLYE-NSZ-X006 Red 150 200 2.2 30 620 150 120
DZ-3030RLYE-NSZ-X004 Super red 150 200 2.2 20 630 150 120
